3 axle lowbed semi trailers are typically used to transport heavy vehicles (such as cars, buses, and specialized vehicles), rail vehicles, mining machinery, forestry machinery, and construction machinery (including excavators, bulldozers, loaders, pavers, and cranes). A low center of gravity improves stability and safety, while also enhancing the ability to transport extra-high loads. The load capacity of a low-bed semi-trailer varies depending on the number of axles and tire size. The greater the number of axles, the greater the load, ranging from 20 to 150 tons.
1. Suitable for transporting various machinery and equipment, large items, road construction equipment, large storage tanks, power plant equipment, and various steel products.
2. Loading dimensions can be customized to meet customer requirements to accommodate a variety of specialized cargo.
3. The low frame and platform ensure stability during transportation, making it suitable for transporting various construction machinery, large equipment, and steel products.
4. Loading capacity, overall dimensions, and other configurations can be customized to meet specific needs.
We want your semi-trailer to be unique and stylish, and we can accommodate any customization needs, including color, logo, tires, and more. If you require further customization, please contact us and we'll provide you with the best price.
| Trailer Model | Lowbed Trailer |
| Overall Dimension (Lx W x H) | 13000*3000*1650mm |
| Loading Weight | 60Tons |
| Tare Weight | 8Tons |
| Main Beam | Q345B, Main frame is height 500mm, upper plate 16mm, down plate 18mm, middle plate 10mm |
| Side Beam | Q235B, 16# channel steel |
| Rim | 8.25*22.5 |
| Landing Gear | Standard 28Tons |
| King Pin | 50# (2 inches) or 90# (3.5 inches) |
| Suspension System | Mechanical or air suspension |
| Axle Brand | FUWA 13-16Tons |
| Tire Type and quantity | 1100R20 12units |
Nude and wax available, shipped by bulk carrier, flat deck, or roll-on/roll-off.
1. Waxing: The wax spraying process on the 3 axle lowbed trailer body is designed to protect it from seawater corrosion during transportation.
2. Packaging: Secure the lowbed semi trailer with steel wire to protect it during transportation.
3. Shipping: Reliable logistics services from a reputable freight provider ensure safe and timely delivery.
We are Chengda Group, located in Jinan, Shandong. We have 20 years of export experience and specialize in a variety of semi-trailers, including flatbed trailers, lowbed semi-trailers, and dump trailers. Our products are currently exported to over 60 countries and regions, including Africa, the Middle East, Southeast Asia, and the Americas. We have a professional after-sales service team to promptly resolve any issues.
